Ultra-thin 56 Keys IP68 Desktop Stainless Steel Washable Keyboard
DESCRIPTION:
56 keys compact format IP68 dynamic vandal proof stainless steel industrial keyboard, industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm with excellent tactile feeling for stable and accurate data input, movable stand alone DESK TOP VERSION, or mountable desktop with mounting holes on the bottoms for fixing. Which is good for outdoor application with direct dynamic water, oil,dirt, salt mist etc, IP68 dynamic trackball module with direct drain pipe module with direct drain pipe is optional, no rust risk and anti-salt spray corrosion.
DIMENSIONS: 228.0mm x 108.0mm x 20mm(L x W x H)
| MECHANICAL DATA | ELECTRICAL DATA |
Actuator/keys: 56 keys, super quality SUS304 brushed stainless steel
Key top style: Protuberant rectangular keys, laser engraved & etched legends & raised braille on keys are available
Key Size: 10.0mm x 10.0mm for normal keys, 10.0mm x 28.0mm for enter key, 10.0mm x 70.0mm for space bar.
Key travel: 0.45mm short stroke.
Actuation Force: 3.2N+/-0.1N for key 14.0mm x 14.0mm (pressure point) 4N+/-0.1N for key 14.0mm x 28.0mm (pressure point)
Switch life: more than 1 million of operations.
Stainless Steel Housing: super quality brushed stainless steel.
G.W.: 2.00KGs
Dimensions: 273.0mm x 108.0mm x 34.2mm (L x W x H) | Supply Voltage: +5V DC +/-5%
Current Rating: appr. 30mA
EMC Standard: EN 55032:2015 EN 55035:2017
Lifespan > 5 years
Switch Contact Material: Gold-on-Gold key switch technology PCB.
Interface: PS2, USB available.
OS: All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed). |
| ENVIRONMENTAL ADAPTABILITY |
Operating temperature: -20℃ to +60℃
Storage temperature: -30℃ to +70℃
Operating RH: 30-90%
Atmospheric pressure: 60-106Kpa.
Saline mist: 96 hours, IEC 60512-6
Damp heat test at + 40oC: 21 days, IEC 60512-6
Dry heat test at + 85oC: 10 days, IEC 60512-6 |
| RELIABILITY |
RoHS Compliant, CE and FCC, ESD
Protection Level: IP68(front panel)
Vandal resistant IK09
Key Lifespan >1 million actuations
MTBF >20000H
MTTR <30min |
MAIN FEATURE
The keyboard can be dynamic washable with water and other liquids.
Imposing stainless steel design, specially designed keyboards meet the highest demands with regard to design, functionality, longevity and high protection level.
Stainless steel fascia and key-tops guard willful destruction, vandal-proof, against corrosion, weather-proof especially under extreme climatic conditions, water proof/dirt proof, operation under hostile environments.
Waterproof execution according to IP68 protection from top panel.
An excellent tactile feel with full-long travel switches and allow users to achieve fast and accurate data input without any noise. With firm tactile perception for comfortable operation
Internet friendly key layout, key-tops are laser-etched in legends and characters for easy readability, long life to prevent lettering rub-off.
Metal keys are protected against twisting and levering which can not be dislodged from front, or defaced removing key covers.
Ease of customizing with multiple languages, to accommodate foreign or custom variants.
Complete electronic modules including controller in close consultation with our customers are available.
PS/2, USB connection plug and play with PC via PC existing OS driver, no needing of install separate driver.
